ABB LDGRB-01 (3BSE013177R1)

The ABB LDGRB-01 (3BSE013177R1) is a Local Display Unit (LDU) used in ABB's AC 800M and Advant Controller 800 automation systems. Below are its key technical parameters:

Display Specifications:

Display Type: LCD (Liquid Crystal Display)

Display Size: Typically 2 lines x 16 characters (or similar, depending on variant)

Backlight: Yes (for visibility in low-light conditions)

Electrical Specifications:

Power Supply:

 1. Voltage: Typically 24V DC (from controller backplane)

 2. Power Consumption: Low power (exact value may vary, usually <5W)

Communication & Interface:

Connection:

 1. Direct connection to the controller via backplane mounting

 2. No separate communication cables required (integrates with the controller unit)

Protocol Support: Proprietary communication with AC 800M/Advant Controller

Physical Specifications:

Mounting: Front-mounted on the controller unit

Dimensions: Compact design (exact dimensions may vary, typically around 100mm x 50mm x 30mm)

Weight: Lightweight (usually <200g)

Environmental Specifications:

Operating Temperature: 0°C to +55°C (32°F to 131°F)

Storage Temperature: -40°C to +70°C (-40°F to 158°F)

Humidity: 5% to 95% (non-condensing)

Protection Class: Typically IP20 (for indoor use)

Functionality:

Used for local monitoring and basic configuration of the controller

Displays system status, alarms, and parameter values

May include navigation buttons for menu access

Typical Applications:

Process automation

Industrial control systems

Power generation & distribution

===================================================================================================================================================================
