ABB REF615 HBFFAEAGNBA1ANB1XD

Product Overview:

The ABB REF615 HBFFAEAGNBA1ANB1XD is a multifunctional protection and control device specifically designed for medium-voltage distribution networks. It is mainly used for feeder protection, transformer protection, and distribution automation applications. The device offers high reliability, flexibility, and scalability, making it suitable for industrial, commercial, and utility sectors.

Technical Specifications:


Voltage Range: 1 kV to 52 kV (depending on the specific application)

Rated Current: 600 A to 6300 A

Rated Voltage: 420 V to 690 V

Communication Interfaces: Supports RS485 and Modbus RTU protocols

Protection Class: IP54

Dimensions: 360 × 250 × 180 mm

Weight: Approx. 10 kg

Features:


Modular Design: Modular input and output units, supporting additional analog and switch I/O to meet diverse application requirements.

Fault Recording Function: Provides detailed fault records, capturing electrical variations during faults to support fault analysis.

Flexible Configuration Options: Offers multiple standard configurations; protection logic and functions are optimized for the Chinese market and can be graphically configured via the PCM600 device management tool.

Multi-Level Access Rights: Defines four access levels—viewer, operator, engineer, and administrator—to ensure secure operation.

Quick Installation and Testing: Plug-in structural design enables fast installation and testing, with factory preset feeder protection logic.

Application Scenarios:

Widely used in utility substations and industrial distribution systems for feeder protection, control, measurement, and monitoring.

Additional Information:

This device belongs to the ABB Relion® 615 series, and is part of the ABB REF615E family, designed for distribution networks with advanced protection, monitoring, and control functionalities.

The ABB REF615 HBFFAEAGNBA1ANB1XD is a powerful and technologically advanced protection and control device, suitable for various industrial and power system applications.

===================================================================================================================================================================
