The PM665 is a member of ABB's renowned M2M (Machine to Machine) line of programmable logic controllers (PLCs) and is specifically a Power Management Relay (PMR). Its primary function is to ensure the reliability, safety, and stability of electrical power systems, particularly in generator, busbar, and mains switching applications.
Product Category: Power Management Relay / Controller
Model: PM665
Ordering Code: 3BDS005799R1 (This specific code often refers to a complete kit or a unit with a specific firmware or option set)
Description: A versatile controller for automatic mains failure (AMF), generator control, and power management systems with extensive I/O and communication capabilities.
Standards Compliance: IEC 60255, UL 508, CSA C22.2, ABS, DNV, GL, LR, and other marine and industrial standards.
Power Supply:
Operating Voltage: A wide range of supply voltages are supported through various modules, typically:
24/48 V DC
24/48/125 V DC (with special order)
110/120 V AC
220/240 V AC
Power Consumption: Typically around 10-15 W.
Inputs:
Digital Inputs (DI): Typically 11 optically isolated digital inputs. They can be configured for various voltage levels (e.g., 24V DC, 48V DC, 110V AC, 220V AC).
Analog Inputs (AI): Typically 8 analog inputs. These can be configured for:
Voltage (0-500V AC L-L directly, or via PTs)
Current (1A or 5A AC directly, or via CTs)
Temperature (via Pt100 sensors)
DC signals (0/4-20mA, 0-10V)
Outputs:
Relay Outputs (RO): Typically 10 Form C (changeover) relay outputs. Common ratings:
Rated Load: 5 A at 250 V AC / 30 V DC
Max. Breaking Capacity: 1250 VA / 150 W
Analog Output (AO): Typically 1 configurable analog output (0/4-20 mA or 0-10 V).
The PM665 is pre-programmed with a comprehensive library of protection and measurement functions:
Voltage (V): V_L-N, V_L-L, average voltage, phase sequence, under/over voltage.
Current (I): Per phase current, neutral current, average current, under/over current.
Frequency (f): System frequency, under/over frequency, rate of change of frequency (df/dt).
Power: Active power (P), Reactive power (Q), Apparent power (S), Power Factor (PF).
Energy: Import/Export of active and reactive energy.
Engine Monitoring: For generator control, it can monitor parameters like engine temperature, oil pressure, fuel level, and running hours.
Protection Functions: Numerous built-in protection features for generators, busbars, and mains, including reverse power, unbalanced load, and multi-stage timers.
Programming Software: ABB's M2M (Machine to Machine) Programming Tool (now often integrated into or succeeded by ABB's Automation Builder IDE).
Communication Ports:
Front Port: RS-232 for local programming and configuration.
Rear Ports: Multiple communication options via plug-in modules:
RS-485 (Modbus RTU protocol is standard)
Profibus-DP
CANopen
Ethernet (with TCP/IP protocol)
Protocols: Primarily Modbus RTU (de facto standard). Other protocols like Profibus-DP, CANopen, and TCP/IP are available with specific communication modules.
Housing: Plastic casing designed for DIN rail mounting.
Dimensions (H x W x D): Approximately 155 x 145 x 125 mm.
Weight: Approximately 1 kg (2.2 lbs).
Front Panel: Includes a backlit graphical LCD display and a keypad for local operation and monitoring.
Operating Temperature: -25°C to +70°C (-13°F to +158°F).
Storage Temperature: -40°C to +85°C.
Relative Humidity: 5% to 95% (non-condensing).
The PM665 is designed for complex power management tasks, including:
Automatic Mains Failure (AMF) / Automatic Transfer Switch (ATS) Controllers
Generator Set (Genset) Control and Protection
Mains Parallel Operation
Load Shedding and Load Sharing
Power Management Systems (PMS) for marine, offshore, and industrial plants.
Monitoring and Control of Multiple Generators in a single system.
Inventory//Affordable prices//Excellent quality//Imported with original packaging
===================================================================================================================================================================
First hand source//affordable price//Spot inventory!
•Shipping Port: Xiamen
•Manager: Rhonda•E-mail: sales7@saulplc.com
•Tel/WhatsApp/Wechat: + 86-15359273796
•Ship to you via Fedex/DHL/TNT/UPS/EMS
•Package: Original packing with cartons
