ABB SPIIT13

 1. Product Overview and Function

• The ABB SPIIT13 is primarily described as an INFI-NET to INFI-NET local transmission module 1 and also referred to as an analog I/O module 25. It is designed for industrial automation, facilitating data transmission and signal routing within INFI-NET networks 1.

• It supports network expansion and integration in industries like power, petrochemicals, and general automation 1.


2. Key Technical Specifications

• Dimensions:

  • Height: 358.14 mm

  • Width: 271.78 mm

  • Depth: 73.66 mm 1.

• Weight:

  • Net weight: 0 kg (excluding battery or packaging) 1.

  • Includes a 5g lithium button battery (WEEE Category 5) 1.

• Environmental Compliance:

  • Conforms to CE marking and EMC96 Directive (89/336/EEC) for electromagnetic compatibility 1.

• Electrical Specifications (for analog module variant):

  • Input Voltage: 24V DC ± 20% 10.

  • Output Power: 500W 10.

  • I/O Channels: Multiple analog input/output channels (exact number not specified in search results, but typical for such modules) 2.

  • Communication Protocols: Supports Ethernet, RS485, and industrial standards like IEC 61131-3 10.

• Operating Conditions:

  • Temperature Range: -20°C to 50°C (for analog module variant) 10, though other variants may differ.

  • Protection Rating: IP65 10.

3. Design and Features

• Compact and Robust Design: Built for industrial environments with high reliability and anti-interference capabilities 110.

• High Precision: Offers accurate analog signal conversion 2.

• Modularity: Supports modular expansion for flexible I/O configuration 10.

• Ease of Integration: Compatible with ABB automation systems and other industrial networks 2.

4. Applications

• Used in:

  • Power Industry: Substation automation, grid monitoring 1.

  • Process Industries: Chemical, petroleum, and pharmaceutical sectors for process control 12.

  • Manufacturing Automation: Production line control and sensor/actuator interfacing 24.

5. Installation and Maintenance

• Installation: Typically mounted on DIN rails 10.

• Maintenance: Designed for minimal maintenance, with remote diagnostics capabilities 10.

6. Additional Notes

• The SPIIT13 is sometimes interchangeably referred to as INIIT13 in certain contexts 210.

• It is part of ABB's broader industrial automation portfolio, which includes DCS (Distributed Control System) components 410.

Summary of Key Parameters:

===================================================================================================================================================================
