The ABB TU810V1 3BSE013230R1 is a Compact Module Termination Unit (MTU) designed for industrial automation systems. Below is a detailed technical parameter table summarizing its key specifications, followed by a breakdown of its features and applications:
| Parameter Category | Specification Details |
|---|---|
| Model Number | TU810V1 3BSE013230R1 |
| Brand | ABB |
| Product Type | Compact Module Termination Unit (MTU) |
| Dimensions (L × H × W) | 64 mm × 170 mm × 58.5 mm |
| Weight | 0.2 kg |
| Channels | 16 signal terminals (2×8 configuration) |
| Rated Voltage | 50 V |
| Rated Current | 2 A per channel; Maximum 5 A |
| Wire Compatibility | Solid: 0.2–4 mm²; Stranded: 0.2–2.5 mm² (24–12 AWG) |
| Communication Interface | ModuleBus (for ABB S800 I/O systems) |
| Dielectric Strength | 500 V AC |
| Protection Rating | IP20 (per IEC 60529) |
| Operating Temperature | –25°C to +70°C |
| Storage Temperature | –40°C to +85°C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Installation | DIN rail mounting |
| Mechanical Keying | 2 keys with 6 positions each (36 configurations) |
Compact Design: Optimized for space-efficient installation in control cabinets, making it suitable for high-density industrial environments
Passive Unit: Serves as an interface for field wiring to I/O modules, facilitating signal transmission between sensors, actuators, and controllers
ModuleBus Distribution: Distributes ModuleBus signals to I/O modules and subsequent MTUs, ensuring correct address generation for I/O modules
Mechanical Keying: Prevents incorrect insertion of I/O modules via configurable keys, enhancing system reliability
High Reliability: Built with quality components for stable performance in harsh industrial conditions (e.g., humidity, temperature variations)
