ABB AI02 Overview

The ABB AI02 is an analog input module within the ABB Ability™ Symphony® Plus system, designed for high-precision acquisition of field process signals.

Key Features

Channels: 16 individually configurable analog input channels; each can be independently set for 4-20 mA or 1–+5 VDC signal ranges.

Resolution: Selectable 12- to 16-bit A/D conversion with configurable polarity. The module uses a single 16-bit A/D converter, updating all 16 channels within 100 ms.

Isolation: Each channel provides 1×16 group isolation with 1500 V dielectric strength, sustaining isolation for up to 1 minute.

Power Supply: 24 VDC ±10% (typical 100 mA); field I/O power also 24 VDC ±10%, providing 20 mA per channel.

Short-Circuit Protection: Each channel supports a maximum of 96 mA; open-circuit detection within 5 seconds.

HART Support: Compatible with HART v5.4; includes one HART modem per module, supporting up to 24 secondary HART variables (up to 4 per channel).

Environmental Tolerance:

Operating temperature: -40 °C to +70 °C

Storage temperature: -40 °C to +85 °C

IP20 protection rating

Certified to IEC 60529, ISA S71.04, and other industrial standards.

Typical Applications

Process Industries: Chemical, oil & gas, and pharmaceutical sectors requiring high-accuracy acquisition of analog variables such as flow, pressure, and temperature.

Process Control Systems: Works with ABB 800xA, PCS 6000, and similar platforms for signal digitization, monitoring, and alarm management.

HART Field Instruments: Enables remote parameter reading and configuration via the built-in HART modem.

Interface and Configuration

FC 221: Defines general operating parameters for the AI module.

FC 222: Configures channel-specific parameters, such as engineering units, alarm limits, and resolution.

Selection Guidelines

Signal Range: Choose 4-20 mA or 1–+5 VDC based on field instrument output.

Resolution Requirement: Select 16-bit when high measurement precision is needed.

HART Requirement: Verify the number of secondary variables and update rate (typical 2.5 s, maximum 8 s).

Environmental Conditions: Ensure compliance with field temperature, humidity, and protection requirements.

Summary
The ABB AI02 is a high-density, configurable analog input module with integrated HART capability, ideal for industrial automation systems that require multi-channel, high-precision signal acquisition in demanding field environments.
