ABB PPC907BE (Part No. 3BHE024577R0101) Overview
| Item | Description | |
|---|---|---|
| Product Positioning | High-performance Programmable Logic Controller (PLC) / control board, commonly used as the “nerve center” of ABB medium-voltage drive systems, linking higher-level controllers with field motors and devices. | |
| Core Processor | 32-bit RISC processor (some sources specify PowerPC 604e, running at approx. 400 MHz). | |
| Memory / Storage | 512 KB RAM + 2 MB Flash (also available in variants with 256 MB SDRAM + 512 MB Flash). | |
| Power Supply | 24 V DC input, typical power consumption ≈ 20 W (some versions rated 4.5 W); certain models include a 500 W output power supply module. | |
| I/O Capability | 24 digital I/O points and 2 analog I/O points (extendable up to 2048 I/O points in total). | |
| Communication Interfaces | RS-232, RS-485, CAN, PROFIBUS DP, Modbus, Ethernet/IP, USB, and other industrial protocols. | |
| Operating Environment | Operating temperature –20 °C to +60 °C (some sources –40 °C to +70 °C); protection class IP65 (also available in IP20 version); DIN-rail mountable. | |
| Dimensions / Weight | Approx. 150 mm × 100 mm × 50 mm; weight ≈ 1.7 kg. | |
| Typical Applications | • Power Systems – Substation automation, protective relay control, load balancing (IEC 61850) • Process Control – Chemical and pharmaceutical multi-parameter coordination control • Energy Management – Smart grid data collection and optimization (Modbus/TCP) • Traffic Control – Intelligent signal systems (CAN bus) • Smart Manufacturing – Integration with ABB robots and servo drives for flexible assembly and material handling. |
|
| Key Advantages | High reliability, versatile I/O and communication options, redundancy support, broad industry compatibility, easy DIN-rail installation, and IP65 protection for harsh industrial environments. |
Summary
The ABB PPC907BE (3BHE024577R0101) is a high-performance industrial PLC designed for demanding automation applications.
Equipped with a 32-bit RISC (or PowerPC) processor and ample memory/storage, it can directly control and process data from thousands of I/O points.
With support for multiple industrial communication protocols (including PROFIBUS, Modbus, Ethernet/IP, and CAN), the PPC907BE delivers reliable real-time control and data acquisition across power, process, energy, transportation, and intelligent manufacturing systems.
Featuring an IP65 protection rating and DIN-rail mounting, it is well-suited for harsh industrial environments and easy on-site installation and maintenance.
