ABB VP01

ABB VP01 is a valve positioner module in the ABB Ability™ Symphony® Plus series, primarily used to control the flow of steam, gas, or water in turbines by precisely adjusting the position of inlet valves. Its key features are as follows:

Control Modes:
Supports closed-loop control of servo valves (using single or redundant position feedback) or open-loop control of current-driven valves.

Response Speed:
Total response time from input to output is less than 1 ms, suitable for high-speed regulation.

Output Capability:
Each servo coil can output up to 500 mA of servo drive current.

Channel Configuration:
A total of 12 channels, including:

2 coil drive channels

2 position feedback channels

2 analog outputs

3 digital inputs

2 digital outputs

1 analog input

Power Supply & Consumption:
24 VDC ± 5% power supply; typical current 330 mA; peak current up to 500 mA (maximum surge up to 2 A).

Environmental Adaptability:
Operating temperature −20 °C to +55 °C; storage temperature −40 °C to +85 °C; relative humidity 20%–95% (non-condensing).
Rated IP20, compliant with industrial vibration, shock, and drop standards.

Certifications:
Meets EU directives such as CE, RoHS, and WEEE; fully compliant with EMC requirements.

Dimensions & Weight:
27 mm (W) × 106 mm (D) × 190 mm (H), weight approx. 294 g.
Uses the standard 190 mm form factor and supports horizontal or vertical installation.

This module is widely used in industrial process control systems requiring high-precision valve positioning—such as steam turbines, gas compressors, and water pumps—enabling rapid and accurate flow regulation within extremely short response times.
